Effects of post-processing on the thermomechanical fatigue properties of laser modified NiTi

Loading...
Thumbnail Image

Date

2019-01-01

Authors

Panton, Boyd
Michael, Andrew
Zhou, Y. Norman
Khan, Mohammad Ibraheem

Advisor

Journal Title

Journal ISSN

Volume Title

Publisher

Elsevier

Abstract

The multifunctional capabilities needed for advanced shape memory alloys (SMA) actuators has been shown to be achievable by locally tuning the properties through laser processing. Before the wide-spread use of these SMAs is realized, a detailed understanding on the long-term stability and functional life span of these material must be achieved. The current study systematically investigates the effects of thermomechanical treatment on laser modified NiTi wires, while comparing them to the original base material. Surface analysis was done using a scanning electron microscope (SEM), while microstructure analysis was performed using transmission electron microscopy (TEM). Mechanical properties were assessed using standard tensile tests and a custom built thermomechanical fatigue. Results showed that the coarse-grains, large inclusions and surface defects associated with as laser modified NiTi resulted in reduced mechanical performance. However, subsequent thermomechanical treatment restored the refined microstructure and mechanical performance similar to the base material while providing the added functionality, thus allowing for laser processed NiTi to be used for manufacturing multiple memory NiTi actuators.

Description

The final publication is available at Elsevier via https://dx.doi.org/10.1016/j.ijfatigue.2017.11.012 © 2019. This manuscript version is made available under the CC-BY-NC-ND 4.0 license https://creativecommons.org/licenses/by-nc-nd/4.0/

Keywords

Fatigue, Microstructure, NiTi, Laser processing, Shape Memory Alloy (SMA)
