Civil and Environmental Engineering

Permanent URI for this collectionhttps://uwspace.uwaterloo.ca/handle/10012/9906

This is the collection for the University of Waterloo's Department of Civil and Environmental Engineering.

Research outputs are organized by type (eg. Master Thesis, Article, Conference Paper).

Waterloo faculty, students, and staff can contact us or visit the UWSpace guide to learn more about depositing their research.

Browse

Now showing 1 - 20 of 909

Implications of Lateral Flow Generation on Land-Surface Scheme Fluxes
(University of Waterloo, 2002) Snelgrove, Kenneth Ross
This thesis details the development and calibration of a model created by coupling a land surface simulation model named CLASS with a hydrologic model named WATFLOOD. The resulting model, known as WatCLASS, is able to serve as a lower boundary for an atmospheric model. In addition, WatCLASS can act independently of an atmospheric model to simulate fluxes of energy and moisture from the land surface including streamflow. These flux outputs are generated based on conservation equations for both heat and moisture ensuring result continuity. WatCLASS has been tested over both the data rich BOREAS domains at fine scales and the large but data poor domain of the Mackenzie River at coarse scale. The results, while encouraging, point to errors in the model physics related primarily to soil moisture transport in partially frozen soils and permafrost. Now that a fully coupled model has been developed, there is a need for continued research by refining model processes and test WatCLASS's robustness using new datasets that are beginning to emerge. Hydrologic models provide a mechanism for the improvement of atmospheric simulation though two important mechanisms. First, atmospheric inputs to the land surface, such as rainfall and temperature, are transformed by vegetation and soil systems into outputs of energy and mass. One of these mass outputs, which have been routinely measured with a high degree of accuracy, is streamflow. Through the use of hydrologic simulations, inputs from atmospheric models may be transformed to streamflow to assess reliability of precipitation and temperature. In this situation, hydrologic models act in an analogous way to a large rain gauge whose surface area is that of a watershed. WatCLASS has been shown to be able to fulfill this task by simulating streamflow from atmospheric forcing data over multi-year simulation periods and the large domains necessary to allow integration with limited area atmospheric models. A second, more important, role exists for hydrologic models within atmospheric simulations. The earth's surface acts as a boundary condition for the atmosphere. Besides the output of streamflow, which is not often considered in atmospheric modeling, the earth's surface also outputs fluxes of energy in the form of evaporation, known as latent heat and near surface heating, known as sensible heat. By simulating streamflow and hence soil moisture over the land surface, hydrologic models, when properly enabled with both energy and water balance capabilities, can influence the apportioning of the relative quantities of latent and sensible heat flux that are required by atmospheric models. WatCLASS has shown that by improving streamflow simulations, evaporation amounts are reduced by approximately 70% (1271mm to 740mm) during a three year simulation period in the BOREAS northern old black spruce site (NSA-OBS) as compared to the use of CLASS alone. To create a model that can act both as a lower boundary for the atmosphere and a hydrologic model, two choices are available. This model can be constructed from scratch with all the caveats and problems associated with proving a new model and having it accepted by the atmospheric community. An alternate mechanism, more likely to be successfully implemented, was chosen for the development of WatCLASS. Here, two proven and well tested models, WATFLOOD and CLASS, were coupled in a phased integration strategy that allowed development to proceed on model components independently. The ultimate goal of this implementation strategy, a fully coupled atmospheric - land surface - hydrologic model, was developed for MC2-CLASS-WATFLOOD. Initial testing of this model, over the Saguenay region of Quebec, has yet to show that adding WATFLOOD to CLASS produces significant impacts on atmospheric simulation. It is suspected, that this is due to the short term nature of the weather simulation that is dominated by initial conditions imposed on the atmospheric model during the data assimilation cycle. To model the hydrologic system, using the domain of an atmospheric model, requires that methods be developed to characterize land surface forms that influence hydrologic response. Methods, such as GRU (Grouped Response Unit) developed for WATFLOOD, need to be extended to taken advantage of alternate data forms, such as soil and topography, in a way that allows parameters to be selected a priori. Use of GIS (Geographical Information System) and large data bases to assist in development of these relationships has been started here. Some success in creating DEMs, (Digital Elevation Model) which are able to reproduce watershed areas, was achieved. These methods build on existing software implementations to include lake boundaries information as a topographic data source. Other data needs of hydrologic models will build on relationships between land cover, soil, and topography to assist in establishing grouping of these variables required to determine hydrologic similarity. This final aspect of the research is currently in its infancy but provides a platform from which to explore for future initiatives. Original contributions of this thesis are centered on the addition of a lateral flow generation mechanism within a land surface scheme. This addition has shown a positive impact on flux returns to the atmosphere when compared to measured values and also provide increased realism to the model since measured streamflow is reproduced. These contributions have been encapsulated into a computer model known as WatCLASS, which together with the implementation plan, as presented, should lead to future atmospheric simulation improvements.
Snow Accumulation in a Distributed Hydrological Model
(University of Waterloo, 2004) Davison, Bruce
The cryosphere is defined as the portions of the earth where water is in solid form. It represents a very important part of the hydrologic cycle, affecting ecological, human and climate systems. A number of component models describing the energy and mass balances of a snowpack have been developed and these component models are finding their way into watershed models and land surface schemes. The purpose of this thesis is to examine the incorporation of a number of snow processes in the coupled land-surface-hydrological model WATCLASS. The processes under consideration were mixed precipitation, variable fresh snow density, maximum snowpack density, canopy interception and snow-covered area (SCA). The first four of these processes were based on similar work done by Fassnacht (2000) on a watershed in Southern Ontario. In the case of this thesis, the work was completed on a basin in Northern Manitoba. A theory of the relationship between snow-covered area and average snow depth was developed and an algorithm was developed to implement this theory in WATCLASS. Of the five snow processes considered, mixed precipitation was found to have the greatest impact on streamflow while the new canopy interception algorithm was found to have the greatest impact on sensible and latent heat fluxes. The development of a new relationship between SCA and average snow depth was found to have a minimal impact in one study case, but a significant impact on the sensible and latent heat fluxes when snow fell on a pack that had begun to melt and was partially free of snow. Further study of these snow processes in land-surface-hydrologic models is recommended.
A Planning Model for Optimizing Locations of Changeable Message Signs
(University of Waterloo, 2004) Henderson, Jeffrey
Changeable Message Signs (CMS) are commonly utilized by transportation agencies to inform motorists of traffic, roadway, and environmental conditions. They may be used to provide information, such as delay and alternate route guidance, in the event of an incident, construction or a roadway closure. The effectiveness of CMS in managing freeway traffic, however, is a function of many factors including the number of CMS installations, the location of CMS, the messages displayed, varied traffic network characteristics, and drivers' response to incident conditions and CMS information. The objective of this thesis is to develop a CMS location planning model that can be used by transportation agencies to develop a CMS location plan that could achieve the largest long-term benefit to the system. This research is mainly motivated by the lack of systematic, robust and practical methods for locating CMS. State-of-practice methods rely mostly on the practitioner's experience and judgement. Other methods fail to incorporate reasonable driver behaviour models, consider time-varying demand, allow for computational efficiency on large networks, or consider the spatial variation of incidents on a traffic network. A new CMS location optimization model has been developed that is unique in both model realism and computational efficiency. The model incorporates several components to estimate incident delay, predict driver response, estimate network-wide benefit, and choose those CMS locations that would provide the most benefit. Deterministic queuing methods are used in conjunction with historic incident characteristics to approximate the delay impact of an incident with and without CMS. A discrete choice model is used to predict the rate at which drivers would switch from the incident route to a less congested alternative under CMS information. A network traffic assignment model is then incorporated in an attempt to estimate the resulting traffic induced by incidents. Genetic algorithms are utilized as an optimization technique to choose a set of CMS that would provide the most benefit. An extensive computational analysis was performed on both a hypothetical network and a segment of Highway 401 through Toronto. A sensitivity analysis was performed to test the model's response to parameter and data estimation errors. The model was found to be most sensitive to the diversion model parameters. The model produced reasonable results with locations selected upstream of major freeway interchange diversion points. Considering the additional components included in the proposed model, and its ability to consider more location schemes, the proposed model may be considered superior to previous CMS location models.
Numerical Simulations of Undrained Granular Media
(University of Waterloo, 2004) Olivera Bonilla, Roberto Rafael
The objective of the present study was to develop a fluid flow-coupled distinct element model capable of capturing the undrained behaviour of granular soils by considering fundamental physical mechanisms that involve fluid flow and particle interaction. The method considers granular media as assemblies of ellipsoidal particles arranged on a plane and interacting by means of contact forces. Saturation effects are incorporated by assuming that particles are immersed in fluid, the flow of which is simulated as occurring through a network of conduits. The flow through conduits is according to a Hagen-Poiseuille relation; a transient solution is obtained by solving a system of differential equations. The developed fluid-flow coupled distinct element was used to conduct various numerical simulations and the mechanisms of undrained deformations were examined from a micromechanical point of view. The dissertation begins with a literature review on the undrained behaviour of granular materials as observed in laboratory experiments. A review of previous attempts to simulate undrained tests micromechanically is also presented, and the advantages and disadvantages of various methods are examined. The capability of the developed model to simulate two-dimensional fluid-flow and pressure dissipation problems is demonstrated by means of comparisons with analytical solutions. Fluid pressure dissipation problems are qualitatively compared with Terzaghi's one-dimension theory of consolidation. It is shown that transient flow problems are accurately modelled by the fluid flow network approach. Simulated compression tests were carried out to examine the effects of different confining pressures and initial densities on the macroscopic response. The results compare favorably with those commonly observed in undrained laboratory experiments. Simulated tests are analyzed from a micromechanical point of view. It is shown that macroscopic behaviour can be traced to changes in micromechanical fabric descriptors. The effects of the interparticle friction angle on the undrained behaviour of the assemblies are investigated. The undrained strength is considerably increased by increasing interparticle friction. The main mechanism found to be responsible for the development of higher strength is the tendency of the specimens to dilate during shear distortion. The effects of the principal stress direction on the macroscopic response are examined. The behaviour of initially anisotropic samples is significantly altered by the direction of the principal stresses relative to the anisotropy direction. It is demonstrated that macroscopic permeability of the media has a considerable effect on the strength. This behaviour is attributed to the inhomogeneity of pore pressure distributions which increases with decreased permeability. The results presented are generally in agreement with observations previously reported from laboratory experiments. The possible applications of the model for future research are also discussed.
Risk-Based Decision Support Model for Planning Emergency Response for Hazardous Materials Road Accidents
(University of Waterloo, 2004) Hamouda, Ghada
Hazardous Materials (HazMat) are transported throughout Canada in a great number of road shipments. The transportation of HazMat poses special risks for neighboring population and environment. While HazMat accidents are rare events, they could be catastrophic in nature and could result in substantial damage to nearby communities. Effective emergency response plays an important role in the safe transportation of HazMat. Transportation of HazMat involves different parties, including shippers, regulators, and surrounding communities. While the shipping party is responsible for safe delivery of HazMat shipments, it is the responsibility of local emergency service agencies to respond to accidents occurring within their jurisdictions. In this research, the emergency response to HazMat transport accidents is assumed to be delegated exclusively to specially trained and equipped HazMat teams. This research proposes a new comprehensive systematic approach to determine the best location of HazMat teams on regional bases utilizing HazMat transport risk as a location criterion. The proposed model is the first to consider emergency response roles in HazMat transport risk analysis, and was intended as an optimization tool to be used by practitioners for HazMat emergency response planning. Additionally, the proposed model can be used to assess risk implications in regards to current locations of HazMat teams in a region, and to develop effective strategies for locating HazMat teams, such as closing and/or relocating teams in the region. The model investigates how HazMat team locations can be tailored to recognize the risk of transporting HazMat and would provide a more objective set of input alternatives into the multi-criteria decision making process of regionally locating HazMat teams. The proposed model was applied to the region of southwestern Ontario in effort to illustrate its features and capabilities in the HazMat emergency response planning and decision making process. Accordingly, the model provided very useful insights while reviewing several HazMat team location strategies for the southwestern Ontario region and investigating tradeoff among different factors. This research contributes to a better understanding of emergency response roles by reducing HazMat transport risks, and will greatly benefit both researchers and practitioners in the field of HazMat transport and emergency response.
Measurement of Ventilation and Drying of Vinyl Siding and Brick Clad Wall Assemblies
(University of Waterloo, 2004) Van Straaten, Randy
Control of moisture and heat flow through building enclosure assemblies is a critical component of overall building performance. This thesis shows that significant drying of moisture in wall assemblies is possible and that ventilation of cladding significantly increases the rate of drying in some assemblies without having detrimental impact on the enclosures thermal performance. A review found that thermal and moisture buoyancy, wind pressure gradients and mechanical equipment drive ventilation airflow. This ventilation flow can theoretically increase the effective water vapour permeance and thermal conductivity. Ventilation has the potential to increase outward drying through relatively impermeable claddings at the low flows expected to occur in service. The impact on thermal conductance is much less. A methodology for assessing the complicated airflow resistance characteristics of lap sidings was developed and applied to a representative vinyl siding. Field drying studies showed that the sample tested is well ventilated. Field brick veneer clad wall samples were also tested for system airflow resistance over a range of driving pressures. Theoretical predictions under-estimated the measured flow rate for given steady driving air pressures. Measurements of naturally driven cavity air speeds and smoke pencil testing showed that flow rates were commonly occurring that would in theory significantly affect the hygrothermal performance of the walls. This was confirmed with field drying studies. A field drying study of east-facing test wall with vinyl siding and brick veneer cladding was conducted in Waterloo, Ontario, Canada. Significant amounts of drying and inward moisture redistribution were measured. Wall sheathing dried quickly in hot summer conditions but in some cases significant inward driven moisture flow occurred. In cool and cold weather the wall dried more slowly and much less moisture moved inward. Increased cladding ventilation significantly increased drying rates and reduced internal wall assembly moisture levels. It was concluded that cladding ventilation acts to increase the effective vapour permeance of cladding and to reduce solar driven inward vapour drives. The use of spun bonded polyolefin sheathing membrane in lieu of #15 asphalt impregnated felt was found to improved hygrothermal performance in the test walls. The difference observed was concluded to be due to the higher vapour permeance of the spun bonded polyolefin and may not hold for wall assemblies with lower permeance sheathings (e. g. oriented strand board and foam plastic). Walls clad with vinyl siding dried faster than those clad with brick veneer. It was concluded that the vinyl siding is a well ventilated cladding system.
A Mathematical Model for Winter Maintenance Operations Management
(University of Waterloo, 2005) Trudel, Mathieu
Scheduling of winter maintenance operations such as plowing or salting is a difficult and complex problem. Proper selection and timing of such operations is critical to their effectiveness, however scheduling decisions must often be made with strict time and resource limitations imposed upon them. A decision support system which analyses current road conditions and makes scheduling suggestions based on them would be a valuable step toward improving the quality of treatment, while simultaneously reducing the burden of scheduling on maintenance managers. This thesis proposes a real-time scheduling model based on an Operations Research framework that can be used by maintenance managers to develop and evaluate alternative resources allocation plans for winter road maintenance operations. The scheduling model is implemented as an Integer Linear Program and is solved using off-the-shelf software packages. The scheduling model takes into account a wide range of road and weather condition factors such as road network topology, road class, weather forecasts, and contractual service levels, and produces a vehicle dispatch schedule that is optimal with respect to operating costs and quality of service. A number of heuristics are also explored to aid in efficient approximations to this problem.
The Analysis of Seasonally Varying Flow in a Crystalline Rock Watershed Using an Integrated Surface Water and Groundwater Model
(University of Waterloo, 2005) Randall, Jefferey
Researchers, explorers, and philosophers have dedicated many lifetimes attempting to discover, document, and quantify the vast physical processes and interactions occurring in nature. Our understanding of physical processes has often been reflected in the form of numerical models that assist academics in unraveling the many complexities that exist in our physical environment. To that end, integrated surface water-groundwater models attempt to simulate the complex processes and relationships occurring throughout the hydrologic cycle, accounting for evapotranspiration and surface water, variably saturated groundwater, and channel flows.

The Bass Lake watershed is located in the Muskoka district of Ontario, within a crystalline rock environment consistent with typical Canadian Shield settings. Numerous data collection programs and methods were used to compile environmental and field-scale datasets. The integrated surface water-groundwater model, HydroGeoSphere (Therrien et al. , 2005), was used for all Bass Lake watershed simulation models.

Simulation results were compared to expected trends and observed field data. The groundwater heads and flow vector fields show groundwater movement in expected directions with reasonable flow velocities. The subsurface saturation levels behave as expected, confirming the evapotranspiration component is withdrawing groundwater during plant transpiration. The surface water depths and locations of water accumulation are consistent with known and collected field data. The surface waters flow in expected directions at reasonable flow speeds. Simulated Bass Lake surface elevations were compared to observed surface water elevations. Low overland friction values produced the most accurate Bass Lake elevations, with high overland friction values slightly overestimating the Bass Lake water level throughout the simulation period. Fluid exchange between surface water and groundwater domains was consistent with expected flux rates. The integrated surface water-groundwater model HydroGeoSphere ultimately produced acceptable simulations of the Bass Lake model domain.
Disinfection By-Product Formation in Drinking Water Treated with Chlorine Following UV Photolysis & UV/H₂O₂
(University of Waterloo, 2005) Adedapo, Remilekun
ABSTRACT As far back as the early 1900?s when it was discovered that water could be a mode of transmitting diseases, chlorine was used to disinfect water. In the 1970?s, the formation of disinfection by-products (DBPs) from the reaction of chlorine with natural organic matter was discovered. Since then there have been various studies on alternative disinfectants that could inactivate microorganisms and at the same time form less or no disinfection by-products. More recently the ultraviolet (UV) irradiation has been used to both disinfect and remove organic contaminants in drinking water. Though the use of UV irradiation has been found to be very effective in the inactivation of microorganisms, it does not provide a residual effect to maintain the water?s microbial quality in the distribution system. Due to this, a secondary disinfectant such as chlorine has to be used to achieve microbial stability, suggesting that the formation of chlorination disinfection by-products would still occur but perhaps in different quantities and with different chemical species. In this research, the use of factorial experiments and single factor experiments were used to determine the effects of pH, alkalinity and UV-fluence (dose) on the formation of three classes of disinfection by-products; haloacetic acids (HAAs), haloacetonitriles (HANs) and trihalomethanes (THMs). These disinfection by-products were measured in water samples following post-UV chlorination and the UV treatment was either UV photolysis or UV/H₂O₂. From the factorial experiment results, treatment of synthetic water with UV/H₂O₂, an advanced oxidation process (AOP), produced fewer post-UV chlorination disinfection by-products (PCDBPs) than UV photolysis. For chlorinated PCDBPs, the percentage difference between UV photolysis and UV/H₂O₂ was 55, 65 and 38% for total HAAs (HAA₉), total HANs (THANs) and total THMs (TTHMs) respectively. The percentage difference between UV photolysis and UV/H₂O₂ for brominated PCDBPs was 41 and 42% for HAA9 and TTHMs respectively. Both the use of pH and alkalinity proved to be factors that were significant in affecting the yields of the PCDBPs studied. Increases in alkalinity were found to increase the formation of PCDBPs in the treatment of synthetic water with UV/H₂O₂. Alkalinity had the opposite effect for PCDBP formed under UV photolysis conditions. Increases in pH always decreased the formation of PCDBPs. In the single factor experiments, haloacetic acid concentrations were unaffected as alkalinity was increased but dichloroacetonitrile and chloroform increased in concentration under treatment conditions of UV photolysis followed by chlorination. The UV/H₂O₂ treatment resulted in a decrease in concentration of the PCDBPs. In the pH studies, water samples were subjected only to the UV/H₂O₂ treatments and a reduction in concentration of PCDBPs occurred between pH 7 and 9.
Treatment of Arsenic Contaminated Groundwater using Oxidation and Membrane Filtration
(University of Waterloo, 2005) Moore, Kenneth
Arsenic is a known carcinogen, causing cancers of the skin, lungs, bladder and kidney. Current research suggests that drinking water is the most common pathway for long-term low dose exposure. Arsenic contaminated drinking water has caused serious health problems in many countries including: India, Bangladesh, Argentina, Chile, Taiwan, the United States and Canada. Nanofiltration (NF) is a promising technology for arsenic removal since it requires less energy than traditional reverse osmosis membranes. Several studies have shown that nanofiltration is capable of removing the oxidized form of arsenic [As(V)] while the reduced form of arsenic [As(III)] is poorly removed. To exploit this difference it has been suggested that a pretreatment step which oxidizes the As(III) to As(V) would improve the performance of membrane filtration, but this has never been demonstrated. The research had three objectives: The first was to investigate the ability of NF membranes to treat arsenic contaminated groundwater and evaluate the influence of the membrane type and operating conditions. Secondly, the effectiveness of a solid phase oxidizing media (MnO2) to oxidize arsenite to arsenate was investigated. Lastly, the MnO2 was combined with NF membrane filtration to determine the benefit, if any, of oxidizing the arsenic prior to membrane filtration. A pilot membrane system was installed to treat a naturally contaminated groundwater in Virden, Manitoba, Canada. The groundwater in Virden contains between 38 and 44 µg/L of arsenic, primarily made up of As(III), with little particulate arsenic. In the first experiment three Filmtec® membranes were investigated: NF270, NF90 and XLE. Under all conditions tested the NF90 and NF270 membranes provided insufficient treatment of Virden's groundwater to meet Canada's recommended Interim Maximum Acceptable Concentration (IMAC) of 25 µg/L. The XLE membrane provided better arsenic removal and under the conditions of 25 Lmh flux and 70% recovery produced treated water with a total arsenic concentration of 21 µg/L. The XLE membrane is therefore able to sufficiently treat Virden's ground water. However treatment with the XLE membrane alone is insufficient to meet the USEPA's regulation of 10 µg/L or Canada's proposed Maximum Allowable Concentration (MAC) of 5 µg/L. The effects of recovery and flux on total arsenic passage are consistent with accepted membrane theory. Increasing the flux increases the flow of pure water through the membrane; decreasing the overall passage of arsenic. Increasing the recovery increases the bulk concentration of arsenic, which leads to higher arsenic passage. The second experiment investigated the arsenic oxidation capabilities of manganese dioxide (MnO2) and the rate at which the oxidation occurs. The feed water contained primarily As(III), however, when filtered by MnO2 at an Empty Bed Contact Time (EBCT) of only 1 minute, the dominant form of arsenic was the oxidized form [As(V)]. At an EBCT of 2 minutes the oxidation was nearly complete with the majority of the arsenic in the As(V) form. Little arsenic was removed by the MnO2 filter. The third and final experiment investigated the benefit, if any, to combining the membrane filtration and MnO2 treatment investigated in the first and second experiments. The effect of MnO2 pretreatment was dramatic. In Experiment I, the NF270 and NF90 membranes were unable to remove any arsenic while the XLE removed, at best, approximately 50% of the arsenic. Once pretreated with MnO2 the passage of arsenic through all of the membranes dropped to less than 4 µg/L, corresponding to approximately 91% to 98% removal. The dramatic improvement in arsenic removal can be attributed to charge. All three membranes are negatively charged. Through a charge exclusion effect the rejection of negatively charged ions is enhanced. During the first experiment, As(III) (which is neutrally charged) was the dominant form of arsenic, and was uninfluenced by the negative charge of the membrane. Once oxidized to As(V), the arsenic had a charge of -2, and was electrostatically repelled by the membrane. This greatly improved the arsenic rejection characteristics of the membrane. Nanofiltration alone is not a suitable technology to remove arsenic contaminated waters where As(III) is the dominant species. When combined with MnO2 pre-oxidation, the arsenic rejection performance of nanofiltration is dramatically improved.
Quantifying the Technical Efficiency of Canadian Paratransit Systems Using Data Envelopment Analysis Method
(University of Waterloo, 2005) Yang, Jingtao
Paratransit service operators in Canada are under increasing pressure to improve the operational productivity of their services due to increased demand and tightening financial constraints. To achieve this, Paratransit operators need to know their performance as compared to peer systems and the best practices within the industry. This will enable each operator to identify where and how much improvement should be made in order to be on a par with the industry?s best practices. Little research effort, however, has been devoted to the issue of how to measure and compare paratransit efficiency in a consistent and systematic manner.

This research focuses on evaluating the level of efficiency of individual paratransit systems in Canada with the specific objective of identifying the most efficient service agencies and the sources of their efficiency. By identifying the most efficient systems along with the influencing factors, it is possible that new service policies and management and operational strategies could be developed for improved resource utilization and quality of services. To achieve this objective, this research applies the analysis methodology called Data Envelopment Analysis (DEA) approach which is a mathematical programming based technique for determining the efficiency of individual systems as compared their peers involving multiple performance measures. Annual operating data from Canadian Urban Transit Association for Canadian paratransit systems of year 2001, 2002 and 2003 are used in this analysis. Regression analysis is performed to identify the possible relationship between the efficiency of a paratransit system and some measurable operating, managerial and other factors which could have an impact on the performance of paratransit systems. The regression analysis also allows for the calculation of confidence intervals and bias for the efficiency scores in order to assess their precision.
An investigation of UV disinfection performance under the influence of turbidity & particulates for drinking water applications
(University of Waterloo, 2005) Liu, Guo
UV disinfection performance was investigated under the influence of representative particle sources, including wastewater particles from secondary effluent in a wastewater treatment plant, river particles from surface water, floc particles from coagulated surface water, floc particles from coagulated process water in a drinking water treatment plant, and soil particles from runoff water (planned). Low-pressure (LP) and medium-pressure (MP) UV dose-response of spiked indicator bacteria E. coli was determined using a standard collimated beam apparatus with respect to different particle sources. Significant impacts of wastewater suspended solids (3. 13~4. 8 NTU) agree with the past studies on UV inactivation in secondary effluents. An average difference (statistical significance level of 5% or α=5%) of the log inactivation was 1. 21 for LP dose and 1. 18 for MP dose. In river water, the presence of surface water particles (12. 0~32. 4 NTU) had no influence on UV inactivation at all LP doses. However, when the floc particles were introduced through coagulation and flocculation, an average difference (α=5%) of the log inactivation was 1. 25 for LP doses and 1. 12 for MP doses in coagulated river water; an average difference (α=5%) of the log inactivation was 1. 10 for LP doses in coagulated process water. Chlorination was compared in parallel with UV inactivation in terms of particulate impacts. However, even floc-associated E. coli were too sensitive to carry out the chlorination experiment in the laboratory, indicating that chlorine seems more effective than UV irradiation on inactivation of particle-associated microorganisms. In addition, a comprehensive particle analysis supported the experimental results relevant to this study.
Sustainable Drinking Water Treatment for Small Communities Using Multistage Slow Sand Filtration
(University of Waterloo, 2005) Cleary, Shawn A.
Slow sand filtration is a proven and sustainable technology for drinking water treatment in small communities. The process, however, is sensitive to lower water temperatures that can lead to decreased biological treatment, and high raw water turbidity levels that can lead to premature clogging of the filter and frequent cleaning requirements, resulting in increased risk of pathogen breakthrough. Multistage filtration, consisting of roughing filtration followed by slow sand filtration, can overcome these treatment limitations and provide a robust treatment alternative for surface water sources of variable water quality in northern climates, which typically experience water temperatures ranging down to 2°C. Prior to this study, however, multistage filtration had yet to be systematically challenged in colder climates, including testing of its performance under increased hydraulic loadings and elevated influent turbidity together with cold water conditions. The primary goal of this research was to demonstrate the reliability of multistage filtration for small communities in northern climates with reference to the Ontario Safe Drinking Water Act. In this research, testing was conducted on two different pilot multistage filtration systems and fed with water from the Grand River, a municipally and agriculturally impacted river in Southern Ontario. One system featured pre-ozonation and post-granular activated carbon (GAC) stages, and shallower bed depths in the roughing filter and slow sand filter. The other system featured deeper bed depths in the roughing filter and slow sand filter, two parallel roughing filters of different design for comparison, and a second stage of slow sand filtration for increased robustness. Removal of turbidity, total coliforms, and fecal coliforms under a range of influent turbidities (1 to >100 NTU), water temperatures (~2 to 20°C), and hydraulic loading rates (0. 2 to 0. 8 m/h) were investigated. In addition, the slow sand filters in each pilot system were challenged with high concentrations (~10⁶ oocyst/L) of inactivated Cryptosporidium parvum oocysts. The performance of both pilot multistage filtration systems was highly dependent on the biological maturity of the system and its hydraulic loading rate. In a less mature system operating in cold water conditions (<5°C), effluent turbidity was mostly below 0. 5 NTU during periods of stable influent turbidity (no runoff events) and a hydraulic loading of 0. 4 m/h, however, runoff events of high influent turbidity (>50 NTU), increased hydraulic loadings (0. 6 m/h), and filter cleaning occasionally resulted in effluent turbidity above 1 NTU. Furthermore, in a less mature system operating during runoff events of high turbidity, reducing the hydraulic loading rate to 0. 2 m/h was important for achieving effluent turbidity below 1 NTU. However, in a more mature system operating in warm water conditions (19-22°C), effluent turbidity was consistently below 0. 3 NTU at a hydraulic loading rate of 0. 4 m/h, and below 0. 5 NTU at 0. 8 m/h, despite numerous events of high influent turbidity (>25 NTU). It remains to be seen whether this performance could be sustained in colder water temperatures with a fully mature filter. Removal of coliform bacteria was occasionally incomplete in a less mature multistage system, whereas, in a more mature system operating in warm water conditions (>9°C), removal was complete in all measurements. Furthermore, the average removal of Cryptosporidium was greater than 2. 5 logs in both systems (with hydraulic loading rates ranging from 0. 4 to 0. 8 m/h) and improved with increased filter maturity. Each individual stage of the multistage system was an important treatment barrier in the overall process of turbidity and pathogen removal. The roughing filter was not only important for protecting the slow sand filter from solids loading and increasing its run length, but was also a significant contributor to coliform removal when the system was less mature. Removal of turbidity was significantly improved when the roughing filter was more mature, suggesting that biological treatment was an important treatment mechanism in the roughing filter. Although pre-ozonation was used mainly for the removal of organic carbon and colour, it achieved complete removal of coliform bacteria and was also suspected to be important for enhanced removal of turbidity. The second slow sand filter in series provided additional robustness to the process by reducing effluent turbidity to below 1 NTU during cold water runoff events of high turbidity and increased hydraulic loadings (0. 6 m/h), while achieving effluent below 0. 3 NTU during normal periods of operation. It also provided additional removals of coliforms under challenging operating conditions, and contributed an additional average removal of Cryptosporidium of 0. 8 logs, which resulted in cumulative removal of 3. 7 logs, approximately 1 log greater than all the other challenge tests. Collectively, the entire multistage system performed well with water temperatures ranging down to 2°C, limited filter maturity, elevated raw water turbidities, and increased hydraulic loading rates. Its ability to meet the current Ontario turbidity regulations and greater than 2 log removal of Cryptosporidium over a range of operating conditions, with little or no process adjustment, is a testament to the robustness and minimal maintenance requirements of the process, which are desirable attributes for small water systems that are often located in rural areas. While this research demonstrated the performance of multistage filtration using pilot scale testing, it is important to note that full-scale plants tend to produce significantly better results than pilot facilities, due to long term biological maturation of the system. Overall, multistage filtration is a sustainable and cost-effective technology that, through this research, appears to be a safe, reliable, and robust treatment alternative for small and non-municipal water systems in North America and the developing world. Further, based on its performance with challenging influent water quality and cold water conditions, multistage filtration holds particular promise for small communities in northern climates that are required to meet safe drinking water regulations, but are dependent on surface water sources of variable water quality and temperatures.
Evaluating the Effects of Grain Size and Divalent Cation Concentration on the Attenuation of Viruses and Microspheres through Crushed Silica Sand
(University of Waterloo, 2006) Knappett, Peter
Over the last decade in North America, an increasing number of microbiological drinking water regulations have been used to manage groundwater resources that are potentially influenced by surface water. Regulations such as the Ontario Ministry of Environment Regulation 505, which requires at least a 60 day groundwater travel time between surface waters and drinking water wells, have been created with limited understanding of subsurface pathogen transport processes. Groundwater Under Direct Influence studies (GUDI or GWUDI in USA) are conducted to assess the need to treat well water at an extraction point. Currently, there is a lack of knowledge regarding factors that affect the transport of pathogens through porous media at the surface water-groundwater interface. Such information is required to supply sufficient quantities of drinking water in a cost effective and safe manner.

Factors that affect pathogen transport through porous media include: properties of the pathogen (i. e. surface charge, size, and morphology), properties of the granular media (i. e. mineralogy, size, texture, angularity) and properties of the water (i. e. pH, ionic strength and content, and natural organic matter). This study examines the effects of ionic strength, grain size and influent virus concentrations on pathogen transport in porous media. Fourteen column tests were conducted using the bacteriophage MS2 and 1. 5 µm microspheres; two commonly used non-pathogenic surrogates representative of human viruses and bacteria, respectively. Two size distributions of crushed silica sand, with median grain diameters of 0. 7 and 0. 34 mm, and two ionic strengths of 8 and 95 mmol/L were used. A 2² partial factorial design was used with a minimum of two replicates of each combination of the parameters.

The results show that complete breakthrough of both viruses and microspheres occurred in medium sand at low ionic strength. It was found that increasing ionic strength by Ca²⁺ addition precluded breakthrough of MS2 in both the medium and fine sands. This represents a greater than 8 log reduction in peak effluent concentration and essentially complete attenuation.

In fine sand, with low ionic strength water, a 5 log reduction in peak MS2 concentrations was observed. In the same sand at high ionic strength, no MS2 broke through the column, corresponding to a greater than 8 log removal. Since complete attenuation occurred in both grain sizes at high ionic strength, the effect of higher ionic strength in the fine sand was indistinguishable from the effect observed from raising the ionic strength in the medium sand.

In contrast to the viruses, microsphere transport was essentially unaffected by increasing ionic strength under the conditions investigated. A 1 log reduction in peak concentration was observed in the high ionic strength water in the medium sand. In spite of this, grain size had a profound effect on the attenuation of microspheres. There was no evidence of microsphere breakthrough in any of the fine sand columns at the low or high ionic strengths, yielding a greater than 5 log reduction in microsphere concentration associated with grain size alone. The effect of varying virus concentration was also investigated. It was found that varying the concentration of viruses between 10⁵ and 10⁷ pfu/ml had no discernable effect on their observed transport characteristics; normalised peak breakthrough concentration, percent attenuation and retardation relative to a bromide tracer.

Based on the results from this Thesis, in a riverbank filtration environment, there is reason to expect that, at comparable water qualities and in similar porous media, multiple logarithmic reductions of viruses and bacteria would occur over the much longer (than column length) flowpaths associated with RBF. There is also reason to expect this attenuation capability to vary based on riverbank grain size and water chemistry.
Hydraulic Performance of the Seepage Collection Ditches at the Albian Sands Muskeg River Mine
(University of Waterloo, 2006) Yasuda, Naoki
The tailings pond at the Muskeg River Mine is a large structure with a 11 km-long ring dyke that contains process affected water (PAW) and tailings sand. The dyke is made of permeable tailings sand and therefore it is equipped with seepage collection ditches that are designed to collect water from drains in the dyke but also to intercept seepage water not collected by the drains and transmit it to the seepage pond for recycling. The effectiveness of this seepage collection system was examined at the downgradient end of the tailings pond (Study Area) where near-surface permeable sand is present.

Piezometric level measurements were performed and water samples were collected from a network of 21 piezometers and drive points, and at several other critical locations. Concentrations of major chemical tracers of PAW such as naphthenic acids (NAs) show signs of migration of PAW in the permeable sand deposit, beyond the dyke. This interpretation is supported by stable O and H isotope analysis of water. The interpretation of the piezometric and chemical data revealed that the PAW has migrated past the Inner Ditch but not beyond the Outer Ditch. Elevated hydraulic heads beyond the Outer Ditch prevented further migration. Groundwater locally converges and discharges as surface water in the wet area between the two ditches. Thus, the collection ditch system is currently working effectively to contain PAW.

Numerical modeling of the Study Area was able to reasonably recreate the observed hydraulic conditions. Based on these simulations, it is possible that PAW may be migrating through a permeable layer of sand under the bottom of the dyke and pond, and eventually discharging into the wet area between the ditches. The estimated amount of PAW seepage discharged into the wet area is small compared to the total dyke drainage collected by the ditches.

These conditions described above, however, may change with the progress of the current dyke expansion work. The wet area between the ditches will be buried and the local hydraulic condition is expected to alter. This may reverse the hydraulic gradient across the Outer Ditch and perhaps will facilitate migration of PAW beyond the Outer Ditch. It is recommended that the following key chemical parameters be used in future groundwater quality monitoring efforts to track PAW migration at the Muskeg River Mine: Na⁺ Cl^- , SO₄^2- , and Ca²⁺ ions, stable isotopes of hydrogen and oxygen, and Naphthenic acids (NAs. )
An Evaluation of the Safety and Operational Impacts of a Candidate Variable Speed Limit Control Strategy on an Urban Freeway
(University of Waterloo, 2006) Allaby, Peter
Variable Speed Limit Sign (VSLS) systems enable transportation managers to dynamically change the posted speed limit in response to prevailing traffic and/or weather conditions. VSLS are thought to improve safety and reduce driver stress while improving traffic flow and travel times. Although VSLS have been implemented in a limited number of jurisdictions throughout the world, there is currently very limited documentation describing the quantitative safety and operational impacts. The impacts that have been reported are primarily from systems in Europe, and may not be directly transferable to other jurisdictions, such as North America. Furthermore, although a number of modelling studies have been performed to date that quantify the impacts of VSLS, the VSLS control strategies are often too complex or based on unrealistic assumptions and therefore cannot be directly applied for practical applications. Consequently, a need exists for an evaluation framework that quantifies the safety and traffic performance impacts of comprehensive VSLS control strategies suitable for practical applications in North America. This paper presents the results of an evaluation of a candidate VSLS system for an urban freeway in Toronto, Canada. The evaluation was conducted using a microscopic simulation model (i. e. a model that predicts individual vehicle movements) combined with a categorical crash potential model for estimating safety impacts.

The objectives of this thesis are: 1) to validate a real-time crash prediction model for a candidate section of freeway; 2) to develop a candidate VSLS control algorithm with potential for practical applications; 3) to evaluate the performance of the VSLS control strategy for a range of traffic conditions in terms of safety and travel time; and 4) to test the sensitivity of the VSLS impact results to modifications of the control algorithm.

The analysis of the VSLS impacts under varying levels of traffic congestion indicated that the candidate control strategy was able to provide large safety benefits without a significant travel time penalty, but only for a limited range of traffic conditions. The tested algorithm was found to be insufficiently robust to operate effectively over a wide range of traffic conditions. However, by modifying parameters of the control algorithm, preliminary analysis identified potential improvements in the performance of the VSLS. The modified control strategy resulted in less overall travel time penalty without an adverse impact on the safety benefits. It is anticipated that further modifications to the VSLS control strategy could result in a VSLS that is able to operate over a wide range of traffic conditions and provide more consistent safety and travel time benefits, and it is recommended that the framework used in this study is an effective tool for optimizing the algorithm structure and parameter values.
The Use of Risk Analysis Techniques to Determine the Probability of Producing Non-Compliant Drinking Water: Focusing on Dual Media Rapid Gravity Filtration
(University of Waterloo, 2006) McAllister, Lawrence Brett
The main goal of a drinking water treatment plant is to provide safe drinking water for its consumers. Historically, this was accomplished through monitoring the influent and effluent water quality to ensure that the water quality met a set of guidelines and regulations. However, as the limitations of relying on compliance monitoring become more evident, water utilities and drinking water treatment plants are beginning to utilize risk management frameworks to help provide safe drinking water and to mitigate potential risks. Applying a risk management framework requires an evaluation of potential risks. This systematic evaluation can be performed through using risk analysis methods.

The overall goal of this research is to analyze and evaluate risk analysis methodologies that are used in a variety of engineering fields, select two risk analysis methods, and use them to evaluate the probability of producing non-compliant drinking water from a rapid gravity filtration unit with respect to turbidity.

The risk analysis methodologies that were used in this research were the consequence frequency assessment and computer modelling combined with probabilistic risk analysis. Both of the risk analysis methodologies were able to determine the probability of producing non-compliant water from a rapid gravity filtration unit with respect to turbidity. However, these methodologies were found to provide different numerical results with respect to each other. The consequence frequency assessment methodology was found to be easier to implement; however, the consequence frequency assessment was only able to be performed on one parameter at a time. Computer modelling and probabilistic risk analysis enabled the inclusion of multiple parameters which provided a more comprehensive understanding of the filtration unit.

The primary conclusion from this research is that the risk analysis methods, as they are described in this thesis, are not sufficient to use directly on a rapid gravity filtration unit without further modification. Furthermore, although the risk analysis methods provided some guidance, these methods should only be used as a part of a complete risk management process.
Study of the effect of lateral inhomogeneities on the propagation of Rayleigh waves in an elastic medium
(University of Waterloo, 2006) Nasseri-Moghaddam, Ali
The use of geophysical testing methods has considerable potential to be a cost effective and accurate technique to assess near-surface soil conditions. Multi channel analysis of surface waves (MASW) test is a geophysical non-intrusive test that uses the dispersive characteristic of Rayleigh waves to estimate low strain shear modulus and damping coefficient of near-surface soil. Also, this technique is used to detect underground voids. Recently, MASW technique has gained more attention, partly because of its ease of use and partly because of the significant improvements in data acquisition systems. The theories of MASW test consider the effect of horizontal soil layering, though the effect of lateral inhomogeneities (i. e. cavities and voids), inclined layering and inverse layering (i. e. a layered system in which the top layers are stiffer than the bottom ones) are not addressed properly in these theories.

The objective of this dissertation is to investigate the effect of lateral inhomogeneities on the propagation of Rayleigh waves in an elastic half-space excited by a transient loading. The results can be applied to locate underground cavities using MASW test and to improve the MASW analysis techniques. In lieu of theoretical solutions, two and three dimensional numerical models are constructed to simulate the MASW test. To assure the quality of the obtained data, numerical models are calibrated with Lamb solution. Voids with different sizes and embedment depths are inserted in the medium. Responses along the surface as well as inside the medium are recorded and analyzed in time, frequency, spatial and frequency-wave number domains. Different material types and sources are used to generalize the results. Afterwards, the combined effect of void and layered systems on the surface responses are studied. To verify the results, experimental field and laboratory data are presented and the trends are compared to the numerical results.

It is found that the void starts to vibrate in response to the Rayleigh wave excitation. Due to the vibration of the void energy partitioning occurs. Part of the incident energy is reflected in the form of Rayleigh wave. Another part is converted to body waves, and spread into the medium. The transferred part of the energy is attenuated and has smaller amplitudes. Finally, a part of energy is trapped in the void region and bounces back and forth between the void boundaries, until it damps. The trapped energy is associated to higher modes of Rayleigh waves and excited Lamb waves. The effect of trapped energy is seen as a region in the vicinity of the void with concentrated energy, in frequency domain. The extents of this region depends on the void size, and the frequency content of the incident energy. Thus, in some cases it is possible to correspond the size of the model to the extents of the region with energy concentration.

A new technique is proposed to determine the location of a void, and estimate its embedment depth. The technique is called Attenuation Analysis of Rayleigh Waves (AARW), and is based on the observed damping effect of the void on the surface responses. For verification, the results are compared to experimental field and laboratory data. The observations are in good agreement with the observed numerical results. Further, the AARW technique showed to be a promising tool for void detection.
Mould Resistance of Full Scale Wood Frame Wall Assemblies
(University of Waterloo, 2006) Black, Christopher
The primary objective of this study was to investigate mould growth resistance of different types of wood products which include the sheathing and framing within full scale wall assemblies. Secondary objectives were to investigate the difference in mould growth resistance between borate-treated and untreated wood products as well as provide information about mould growth under different temperature and humidity conditions for treated and untreated wood products.

The objective of the study is to better understand mould growth, and to examine the effects of varying high moisture conditions on wooden products and the mould growth which may result. More importantly this will be examined on full scale wall assemblies; to date mould growth studies have only been performed within a laboratory on small samples of materials. Moreover, this study recreates the conditions which evidently cause mould growth on full scale wall assemblies. Tests were performed within a climate chamber on three full scale wall assemblies. The original scope of this study included an examination of the sheathing and framing components within a full scale wall assembly, however this study will focus mainly on the sheathing.

Results of this study indicate that the relative humidity conditions needed for mould growth on wood are higher than originally believed (i. e. , significantly greater than 80%RH). During the first eight weeks of test number one the relative humidity at the surface of the sheathing was held constant at 95% and little mould growth was observed on the untreated sheathing (mould growth index of 3 or less); little or no mould growth on the treated sheathing (mould growth index of 1 or less). The second and third tests demonstrated that the presence of liquid water greatly accelerated the time to germinations, the amount of mould growth (up to a mould growth index of 6), and the rate of mould growth. All three tests clearly showed that borate-treatment reduced the amount of mould growth; however, the concentration of borate-treatment, and the types of materials treated, does affect the resistance of mould growth. Furthermore, there was some evidence to suggest Borate treatments of the plywood increased the time to germination significantly, from a few weeks to 16 weeks in this study, but once mould growth was initiated, the rate of mould growth was similar to that of the untreated plywood. Two mathematical models to determine mould growth were examined: Viitanen and WUFIBIO (Sedlbauer). Viitanen?s model predicted time to germination and rate of growth rate well for untreated plywood, and WUFIBIO predicted time to germination but not the growth rate. It was also found both models err on the side of caution in predicting mould growth.

Recommendations include improvements to the test method and producers, and for future work.
Temporal Disaggregation of Daily Precipitation Data in a Changing Climate
(University of Waterloo, 2006) Wey, Karen
Models for spatially interpolating hourly precipitation data and temporally disaggregating daily precipitation to hourly data are developed for application to multisite scenarios at the watershed scale. The intent is to create models to produce data which are valid input for a hydrologic rainfall-runoff model, from daily data produced by a stochastic weather generator. These models will be used to determine the potential effects of climate change on local precipitation events. A case study is presented applying these models to the Upper Thames River basin in Ontario, Canada; however, these models are generic and applicable to any watershed with few changes.

Some hourly precipitation data were required to calibrate the temporal disaggregation model. Spatial interpolation of this hourly precipitation data was required before temporal disaggregation could be completed. Spatial interpolation methods were investigated and an inverse distance method was applied to the data. Analysis of the output from this model confirms that isotropy is a valid assumption for this application and illustrates that the model is robust. The results for this model show that further study is required for accurate spatial interpolation of hourly precipitation data at the watershed scale.

An improved method of fragments is used to perform temporal disaggregation on daily precipitation data. A parsimonious approach to multisite fragment calculation is introduced within this model as well as other improvements upon the methods presented in the literature. The output from this model clearly indicates that spatial and temporal variations are maintained throughout the disaggregation process. Analysis of the results indicates that the model creates plausible precipitation events.

The models presented here were run for multiple climate scenarios to determine which GCM scenario has the most potential to affect precipitation. Discussion on the potential impacts of climate change on the region of study is provided. Selected events are examined in detail to give a representation of extreme precipitation events which may be experienced in the study area due to climate change.
